The Value of Ultrasound Evaluation and Marking before Arteriovenous Internal Fistula in Uremia Patients_West China Medical Journal

Authors：

 LIUChun-cheng ¹ , SHIYing-yu ¹ , CUITian-lei ² , LUOYan ¹ , PENGYu-lan ¹ ,  WENXiao-rong ¹

1. Department of Ultrasound, West China Hospital, Sichuan University, Chengdu, Sichuan 610041, P. R. China;
2. Department of Nephrology, West China Hospital, Sichuan University, Chengdu, Sichuan 610041, P. R. China;

Corresponding?author：

WENXiao-rong, Email: hxwenxiaor@126.com

Keywords：

Uremia; Arteriovenous internal fistula; Color Doppler ultrasound; Assessment; Marking

DOI：

10.7507/1002-0179.20140216

Video：

Export PDF Favorites Scan Get Citation

Abstract Full text Figures/Tables Video References Cited by

Objective To explore the value of ultrasound evaluation and marking before arteriovenous internal fistula in end-stage renal disease hemodialysis patients. Methods Twenty-five uremia end-stage patients were admitted into our nephrology department from January 2012 to July 2012. All of the patients had encountered several times of fistula failure or had difficulty in establishing the forearm arteriovenous fistula. We focused on observing the brachial artery, radial artery, cephalic vein, the basilica vein and great saphenous vein. We measured the diameter of the vessels and marked the trend of arteries and veins in the body surface under the ultrasonic navigation. Our goal was to look for appropriate bypass vessels in the elbow and the upper arm. Results Fourteen patients had endured several times of fistula failure. Among the 14 patients, 9 patients completed the surgery of reengineering fistula and autogenous great saphenous vein transplantation, 2 accepted artificial vascular transplantation, 1 completed the removal of blood clots in the left upper limb artificial blood vessels and arteriovenous internal fistula molding, and 2 gave up surgery. Eleven patients could not complete the arteriovenous fistula operation for the fine forearm superficial vein. Of them, 2 patients accepted artificial vascular operation, 6 underwent autogenous great saphenous vein transplantation, 1 with slender radial artery in diameter completed higher position fistula between the brachial artery and median cubital vein, and 2 gave up surgery. Conclusion Arteriovenous internal fistula preoperative ultrasound assessment and marking have very important value in improving the success rate of operation in end-stage uremia patients.

Citation： LIUChun-cheng, SHIYing-yu, CUITian-lei, LUOYan, PENGYu-lan, WENXiao-rong. The Value of Ultrasound Evaluation and Marking before Arteriovenous Internal Fistula in Uremia Patients. West China Medical Journal, 2014, 29(4): 725-727. doi: 10.7507/1002-0179.20140216 Copy

1.	Konner K. Vascular access for dialysis in diabetic patients[J]. Edtna Erca J, 2005, 30(3):148-150.
2.	Konner K, Nonnast-Daniel B, Ritz E. The arteriovenous fistula[J]. J Am Soc Nephrol, 2003, 14(6):1669-1680.
3.	Robbin ML, Oser RF, Lee JY, et al. Randomized comparison of ultrasound surveillance and clinical monitoring on arteriovenous graft outcomes[J]. Kidney Int, 2006, 69(4):730-735.
4.	李晨, 張紅, 楊德民, 等. 高頻彩超在尿毒癥患者動靜脈內瘺術前的應用[J]. 中國血液凈化, 2008, 7(7):363-365.
5.	李盛, 尚繼先. 橈動脈頭靜脈吻合內瘺失敗原因分析[J]. 山西醫藥雜志, 2004, 33(7):614-615.
6.	唐杰, 溫朝陽. 腹部和外周血管彩色多普勒診斷學[M]. 3版. 北京:人民衛生出版社, 2007:285.
7.	Bhandari S, Wilkinson A, Sellars L. Saphenous vein forearm grafts and gortex thigh grafts as alternative forms of vascular access[J]. Clin Nephrol, 1995, 44(5):325-328.
8.	Oto T. Endoscopic saphenous vein harvesting for hemodialysis vascular access creation in the forearm:a new approach for arteriovenous bridge graft[J]. J Vasc Access, 2007, 4(3):98-101.
9.	葉建榮, 馮友賢. 自體大隱靜脈移植在血管外科的應用[J]. 國外醫學·創傷與外科基本問題分冊, 1985, 1(1):5-8.
10.	張信英, 邵振恒, 于鐘毓, 等. 血管移植治療四肢動脈損傷用[J]. 中華顯微外科雜志, 1991, 14(2):104-106.
11.	葉朝陽. 血管通路的功能評估[J]. 中國血液凈化, 2007, 6(7):361-364.
12.	鄭露, 張磊, 戎殳, 等. 老年自體動靜脈內瘺在血液透析中的應用[J]. 中國血液凈化, 2004, 3(12):649-651.
13.	Zwiebel WJ, Pellerito JS. 血管超聲經典教程[M]. 溫朝陽, 譯.北京:人民軍醫出版社, 2008:195.

1. Konner K. Vascular access for dialysis in diabetic patients[J]. Edtna Erca J, 2005, 30(3):148-150.
2. Konner K, Nonnast-Daniel B, Ritz E. The arteriovenous fistula[J]. J Am Soc Nephrol, 2003, 14(6):1669-1680.
3. Robbin ML, Oser RF, Lee JY, et al. Randomized comparison of ultrasound surveillance and clinical monitoring on arteriovenous graft outcomes[J]. Kidney Int, 2006, 69(4):730-735.
4. 李晨, 張紅, 楊德民, 等. 高頻彩超在尿毒癥患者動靜脈內瘺術前的應用[J]. 中國血液凈化, 2008, 7(7):363-365.
5. 李盛, 尚繼先. 橈動脈頭靜脈吻合內瘺失敗原因分析[J]. 山西醫藥雜志, 2004, 33(7):614-615.
6. 唐杰, 溫朝陽. 腹部和外周血管彩色多普勒診斷學[M]. 3版. 北京:人民衛生出版社, 2007:285.
7. Bhandari S, Wilkinson A, Sellars L. Saphenous vein forearm grafts and gortex thigh grafts as alternative forms of vascular access[J]. Clin Nephrol, 1995, 44(5):325-328.
8. Oto T. Endoscopic saphenous vein harvesting for hemodialysis vascular access creation in the forearm:a new approach for arteriovenous bridge graft[J]. J Vasc Access, 2007, 4(3):98-101.
9. 葉建榮, 馮友賢. 自體大隱靜脈移植在血管外科的應用[J]. 國外醫學·創傷與外科基本問題分冊, 1985, 1(1):5-8.
10. 張信英, 邵振恒, 于鐘毓, 等. 血管移植治療四肢動脈損傷用[J]. 中華顯微外科雜志, 1991, 14(2):104-106.
11. 葉朝陽. 血管通路的功能評估[J]. 中國血液凈化, 2007, 6(7):361-364.
12. 鄭露, 張磊, 戎殳, 等. 老年自體動靜脈內瘺在血液透析中的應用[J]. 中國血液凈化, 2004, 3(12):649-651.
13. Zwiebel WJ, Pellerito JS. 血管超聲經典教程[M]. 溫朝陽, 譯.北京:人民軍醫出版社, 2008:195.
