The Initial Study of Real-time Shear Wave Elastography in Parotid and Submaxillary Gland of Healthy Adults_West China Medical Journal

Authors：

 JINYa ,  PENGYu-lan , ZHAOHai-na , SHIYan , HEYu-shuang

Department of Ultrasound, West China Hospital, Sichuan University, Chengdu, Sichuan 610041, P. R. China;

Corresponding?author：

PENGYu-lan, Email: yulanpeng@163.com

Keywords：

Parotid gland; Submaxillary gland; Shear wave elastography

DOI：

10.7507/1002-0179.20150198

Video：

Export PDF Favorites Scan Get Citation

Abstract Full text Figures/Tables Video References Cited by

Objective To study the Young's modulus obtained by the real-time shear wave elastography (SWE) in healthy adults' parotid gland and submaxillary gland and to explore the probable factors affecting the Young's modulus, such as bilateral parotid and submaxillary gland, sex, age, height and weight. Methods There were 35 healthy volunteers who underwent SWE in parotid gland and submaxillary gland between December 3 and 18, 2013. The difference of Young's modulus in bilateral parotid and submaxillary gland, and the modulus values of different sex, age, height and weight groups were also compared. Results The Young's modulus of parotid gland was (8.14±1.78) kPa, and the Young's modulus of submaxillary gland was (11.52±2.34) kPa. The differences of Young's modulus between the two sides of parotid gland and submaxillary gland were not statistically significant (P>0.05); the differences of Young's modulus of parotid and submaxillary gland between different sex, age, height and weight groups had no statistical significance, either (P>0.05). Conclusion The real-time shear wave elastography can be applied to evaluate the elasticity of parotid and submaxillary gland and to lay the foundation for further diagnosis of salivary lesions.

Citation： JINYa, PENGYu-lan, ZHAOHai-na, SHIYan, HEYu-shuang. The Initial Study of Real-time Shear Wave Elastography in Parotid and Submaxillary Gland of Healthy Adults. West China Medical Journal, 2015, 30(4): 692-695. doi: 10.7507/1002-0179.20150198 Copy

1.	Ophir J, Céspedes I, Ponnekanti H, et al. Elastography:a quantitative method for imaging the elasticity of biological tissues[J]. Ultrason Imaging, 1991, 13(2):111-134.
2.	羅建文, 白凈. 超聲彈性成像的研究進展[J]. 中國醫療器械信息, 2005, 11(5):28-36.
3.	Kallel F, Ophir J. Limits on the contrast of strain concentrations in elastography[J]. Ultrasound Med Biol, 1998, 24(8):1215-1219.
4.	趙子卓, 羅葆明. 超聲彈性成像基本原理及技術[J]. 中國醫療器械信息, 2008, 14(4):6-8.
5.	Garra BS. Elastography:current status, future prospects, and making it work for you[J]. Ultrasound Q, 2011, 27(3):177-186.
6.	張倩倩, 王學梅, 李銀燕, 等. 剪切波彈性成像在乳腺良惡性病變鑒別診斷中的價值[J]. 中國臨床醫學影像雜志, 2012, 23(6):385-388.
7.	Guibal A, Boularan C, Bruce M, et al. Evaluation of shearwave elastography for the characterisation of focal liver lesions on ultrasound[J]. Eur Radiol, 2013, 23(4):1138-1149.
8.	Yoon JH, Lee JY, Woo HS, et al. Shear wave elastography in the evaluation of rejection or recurrent hepatitis after liver transplantation[J]. Eur Radiol, 2013, 23(6):1729-1737.
9.	馮卉, 李俊來, 黃炎, 等. 剪切波彈性模量聯合BI-RADS分級定量診斷乳腺結節良惡性的價值[J]. 解放軍醫藥雜志, 2013, 25(5):87-90.
10.	Gweon HM, Youk JH, Son EJ, et al. Visually assessed colour overlay features in shear-wave elastography for breast masses:quantification and diagnostic performance[J]. Eur Radiol, 2013, 23(3):658-663.
11.	王濤, 王學梅, 張義俠, 等. 實時剪切波彈性成像鑒別甲狀腺結節良惡性的定量分析[J]. 中國醫學影像學雜志, 2012, 9(9):684-687.
12.	郭海燕, 張瑞芳, 崔可飛, 等. 剪切波彈性成像技術在慢性腎病診斷中的應用價值[J]. 山東醫藥, 2013, 53(11):74-76.
13.	王健楠, 王學梅, 方毅, 等. 正常成人腮腺及頜下腺實時剪切波彈性成像的研究[J]. 中國臨床醫學影像雜志, 2013, 24(8):540-542.
14.	Arda K, Ciledag N, Aribas BK, et al. Quantitative assessment of the elasticity values of liver with shear wave ultrasonographic elastography[J]. Indian J Med Res, 2013, 137(5):911-915.
15.	徐智章, 俞清. 超聲彈性成像原理及初步應用[J]. 上海醫學影像, 2005, 14(1):3-5.

1. Ophir J, Céspedes I, Ponnekanti H, et al. Elastography:a quantitative method for imaging the elasticity of biological tissues[J]. Ultrason Imaging, 1991, 13(2):111-134.
2. 羅建文, 白凈. 超聲彈性成像的研究進展[J]. 中國醫療器械信息, 2005, 11(5):28-36.
3. Kallel F, Ophir J. Limits on the contrast of strain concentrations in elastography[J]. Ultrasound Med Biol, 1998, 24(8):1215-1219.
4. 趙子卓, 羅葆明. 超聲彈性成像基本原理及技術[J]. 中國醫療器械信息, 2008, 14(4):6-8.
5. Garra BS. Elastography:current status, future prospects, and making it work for you[J]. Ultrasound Q, 2011, 27(3):177-186.
6. 張倩倩, 王學梅, 李銀燕, 等. 剪切波彈性成像在乳腺良惡性病變鑒別診斷中的價值[J]. 中國臨床醫學影像雜志, 2012, 23(6):385-388.
7. Guibal A, Boularan C, Bruce M, et al. Evaluation of shearwave elastography for the characterisation of focal liver lesions on ultrasound[J]. Eur Radiol, 2013, 23(4):1138-1149.
8. Yoon JH, Lee JY, Woo HS, et al. Shear wave elastography in the evaluation of rejection or recurrent hepatitis after liver transplantation[J]. Eur Radiol, 2013, 23(6):1729-1737.
9. 馮卉, 李俊來, 黃炎, 等. 剪切波彈性模量聯合BI-RADS分級定量診斷乳腺結節良惡性的價值[J]. 解放軍醫藥雜志, 2013, 25(5):87-90.
10. Gweon HM, Youk JH, Son EJ, et al. Visually assessed colour overlay features in shear-wave elastography for breast masses:quantification and diagnostic performance[J]. Eur Radiol, 2013, 23(3):658-663.
11. 王濤, 王學梅, 張義俠, 等. 實時剪切波彈性成像鑒別甲狀腺結節良惡性的定量分析[J]. 中國醫學影像學雜志, 2012, 9(9):684-687.
12. 郭海燕, 張瑞芳, 崔可飛, 等. 剪切波彈性成像技術在慢性腎病診斷中的應用價值[J]. 山東醫藥, 2013, 53(11):74-76.
13. 王健楠, 王學梅, 方毅, 等. 正常成人腮腺及頜下腺實時剪切波彈性成像的研究[J]. 中國臨床醫學影像雜志, 2013, 24(8):540-542.
14. Arda K, Ciledag N, Aribas BK, et al. Quantitative assessment of the elasticity values of liver with shear wave ultrasonographic elastography[J]. Indian J Med Res, 2013, 137(5):911-915.
15. 徐智章, 俞清. 超聲彈性成像原理及初步應用[J]. 上海醫學影像, 2005, 14(1):3-5.
