RECONSTRUCTION MODE SELECTION OF ACETABULAR BONE DEFECT AND EFFECT ON ACETABULAR CUP POSITION IN CEMENTLESS TOTAL HIP ARTHROPLASTY_Chinese Journal of Reparative and Reconstructive Surgery

Authors：

CAOLinhu ^1,2 ,  TANLun ² , LINXu ² , WUChao ² , ZENGJun ²

1. Luzhou Medical College, Luzhou Sichuan, 646000, P. R. China;
2. Department of Orthopedics, the Affiliated Zigong Hospital of Luzhou Medical College (the 4th People's Hospital of Zigong City;

Corresponding?author：

TANLun, Email: 1098726536@qq.com

Keywords：

Total hip arthroplasty; Bone defect; Acetabular reconstruction; Rotation center

DOI：

10.7507/1002-1892.20150150

Video：

Export PDF Favorites Scan Get Citation

Abstract Full text Figures/Tables Video References Cited by

Objective To investigate the reconstruction mode selection of acetabular bone defect and the effect on the acetabular cup position in cementless total hip arthroplasty (THA). Methods A retrospective analysis was made on the clinical data of 78 patients (78 hips) with acetabular bone defect according to the selection criteria who underwent THA between February 2008 and February 2014. In 39 cases having acetabular posterosuperior bone defect with defect area less than 30%, impaction bone grafting was performed (group A); in 24 cases having acetabular posterosuperior bone defect with defect area of 30%-50%, structural bone or tantalum block grafting was performed (group B); in 10 cases having acetabular medial wall bone defect with defect area less than 30%, impaction bone grafting was performed (group C); and in 5 cases having acetabular medial wall bone defect with defect area of 30%-50%, titanium mesh combined with impaction bone grafting was performed (group D). There was no significant difference in gender, age, and side between groups A and B, and between groups C and D (P>0.05). The acetabular abduction angle, anteversion, the horizontal and vertical distances of actual and true rotation center after operation were compared. Results The patients were followed up 7-25 months. Prosthesis loosening occurred in 2 cases of group A, sciatic nerve injury and hip joint dislocation in 1 case of group B, respectively. At immediate after operation and last follow-up, there was no significant differences in the horizontal or vertical distance of actual and the true rotation center between groups A and B (P>0.05); significant difference was found in the horizontal distance between groups C and D (P<0.05), but no significant difference in the vertical distance (P>0.05). Difference was statistically significant in the acetabular abduction angle and anteversion between groups A and B (P<0.05), but difference was not significant between groups C and D (P>0.05). Conclusion In patients with acetabular posterosuperior bone defect, reconstruction methods will have effect on acetabular abduction and anteversion; early acetabulum prosthesis loosening may be associated with too large acetabular abduction angle and inappropriate reconstruction methods. In patients with acetabular medial wall bone defect, the vertical distances of rotation center will shift upward in varying degrees, and reconstruction methods have effect on the horizontal distances of rotation center.

Citation： CAOLinhu, TANLun, LINXu, WUChao, ZENGJun. RECONSTRUCTION MODE SELECTION OF ACETABULAR BONE DEFECT AND EFFECT ON ACETABULAR CUP POSITION IN CEMENTLESS TOTAL HIP ARTHROPLASTY. Chinese Journal of Reparative and Reconstructive Surgery, 2015, 29(6): 693-699. doi: 10.7507/1002-1892.20150150 Copy

1.	Brooks PJ. Dislocation following total hip replacement:causes and cures. Bone Joint J, 2013, 95-B(11 Suppl A):67-69.
2.	Patel SR, Toms AP, Rehman JM, et al. A reliability study of measurement tools available on standard picture archiving and communication system workstations for the evaluation of hip radiographs following arthroplasty. J Bone Joint Surg (Am), 2011, 93(18):1712-1719.
3.	Bosker BH, Verheyen CC, Horstmann WG, et al. Poor accuracy of freehand cup positioning during total hip arthroplasty. Arch Orthop Trauma Surg, 2007, 127(5):375-379.
4.	曹林虎, 譚倫, 吳超, 等. 人工全髖關節置換術中改良髖臼中心化技術對雙下肢不等長的影響. 中國修復重建外科雜志, 2014, 28(2):213-217.
5.	Pagnano W, Hanssen AD, Lewallen DG, et al. The effect of superior placement of the acetabular component on the rate of loosening after total hip arthroplasty. J Bone Joint Surg (Am), 1996, 78(7):1004-1014.
6.	Lewinnek GE, Lewis JL, Tarr R, et al. Dislocations after total hip-replacement arthroplasties. J Bone Joint Surg (Am), 1978, 60(2):217-220.
7.	康鵬德, 沈彬, 裴福興. 髖關節翻修術中髖臼骨缺損的評估與重建. 中華骨科雜志, 2013, 33(12):1258-1264.
8.	劉瑞宇, 王坤正, 王春生, 等. 三維表面遮蓋法結合多平面重建在成人髖關節發育不良全髖關節置換術前髖臼評估中的應用. 中國修復重建外科雜志, 2008, 22(6):643-645.
9.	李棟梁, 李佛保, 朱琦, 等. 人工全髖關節置換術中自體骨重建髖臼骨缺損的臨床研究. 中華關節外科雜志(電子版), 2012, 6(1):39-43.
10.	Barrack RL, Newland CC. Uncemented total hip arthroplasty with superior acetabular deficiency. Femoral head autograft technique and early clinical results. J Arthroplasty, 1990, 5(2):159-167.
11.	Jeon DG, Kim MS, Cho WH, et al. Reconstruction with pasteurized autograft-total hip prosthesis composite for periacetabular tumors. J Surg Oncol, 2007, 96(6):493-502.
12.	裴福興. 關節外科手術操作與技巧. 北京:人民衛生出版社, 2008:290-291.
13.	李雄峰, 管國華, 李建有. 髖關節發育不良人工全髖關節置換術中髖臼中心重建. 中國修復重建外科雜志, 2012, 26(9):1037-1040.
14.	Ybinger T, Kumpan W. Enhanced acetabular component positioning through computer-assisted navigation. Int Orthop, 2007, 31 Suppl 1:S₃5-38.
15.	Merle C, Grammatopoulos G, Waldstein W, et al. Comparison of native anatomy with recommended safe component orientation in total hip arthroplasty for primary osteoarthritis. J Bone Joint Surg (Am), 2013, 95(22):e172.
16.	李軍偉, 楊廣輝, 王義生, 等. 髖臼卵圓窩在實現術前預期髖臼杯外展角中的參考價值. 中華骨科雜志, 2012, 32(2):167-172.
17.	鄭鴻, 何冰, 譚宏昌, 等. 不同手術入路髖臼假體放置角度差異對療效的影響. 中華創傷骨科雜志, 2013, 15(8):734-736.
18.	Hirakawa K, Mitsugi N, Koshino T, et al. Effect of acetabular cup position and orientation in cemented total hip arthroplasty. Clin Orthop Relat Res, 2001, (388):135-142.
19.	Eggli S, Hankemayer S, Muller ME. Nerve palsy after leg lengthening in total replacement arthroplasty for developmental dysplasia of the hip. J Bone Joint Surg (Br), 1999, 81(5):843-845.

1. Brooks PJ. Dislocation following total hip replacement:causes and cures. Bone Joint J, 2013, 95-B(11 Suppl A):67-69.
2. Patel SR, Toms AP, Rehman JM, et al. A reliability study of measurement tools available on standard picture archiving and communication system workstations for the evaluation of hip radiographs following arthroplasty. J Bone Joint Surg (Am), 2011, 93(18):1712-1719.
3. Bosker BH, Verheyen CC, Horstmann WG, et al. Poor accuracy of freehand cup positioning during total hip arthroplasty. Arch Orthop Trauma Surg, 2007, 127(5):375-379.
4. 曹林虎, 譚倫, 吳超, 等. 人工全髖關節置換術中改良髖臼中心化技術對雙下肢不等長的影響. 中國修復重建外科雜志, 2014, 28(2):213-217.
5. Pagnano W, Hanssen AD, Lewallen DG, et al. The effect of superior placement of the acetabular component on the rate of loosening after total hip arthroplasty. J Bone Joint Surg (Am), 1996, 78(7):1004-1014.
6. Lewinnek GE, Lewis JL, Tarr R, et al. Dislocations after total hip-replacement arthroplasties. J Bone Joint Surg (Am), 1978, 60(2):217-220.
7. 康鵬德, 沈彬, 裴福興. 髖關節翻修術中髖臼骨缺損的評估與重建. 中華骨科雜志, 2013, 33(12):1258-1264.
8. 劉瑞宇, 王坤正, 王春生, 等. 三維表面遮蓋法結合多平面重建在成人髖關節發育不良全髖關節置換術前髖臼評估中的應用. 中國修復重建外科雜志, 2008, 22(6):643-645.
9. 李棟梁, 李佛保, 朱琦, 等. 人工全髖關節置換術中自體骨重建髖臼骨缺損的臨床研究. 中華關節外科雜志(電子版), 2012, 6(1):39-43.
10. Barrack RL, Newland CC. Uncemented total hip arthroplasty with superior acetabular deficiency. Femoral head autograft technique and early clinical results. J Arthroplasty, 1990, 5(2):159-167.
11. Jeon DG, Kim MS, Cho WH, et al. Reconstruction with pasteurized autograft-total hip prosthesis composite for periacetabular tumors. J Surg Oncol, 2007, 96(6):493-502.
12. 裴福興. 關節外科手術操作與技巧. 北京:人民衛生出版社, 2008:290-291.
13. 李雄峰, 管國華, 李建有. 髖關節發育不良人工全髖關節置換術中髖臼中心重建. 中國修復重建外科雜志, 2012, 26(9):1037-1040.
14. Ybinger T, Kumpan W. Enhanced acetabular component positioning through computer-assisted navigation. Int Orthop, 2007, 31 Suppl 1:S₃5-38.
15. Merle C, Grammatopoulos G, Waldstein W, et al. Comparison of native anatomy with recommended safe component orientation in total hip arthroplasty for primary osteoarthritis. J Bone Joint Surg (Am), 2013, 95(22):e172.
16. 李軍偉, 楊廣輝, 王義生, 等. 髖臼卵圓窩在實現術前預期髖臼杯外展角中的參考價值. 中華骨科雜志, 2012, 32(2):167-172.
17. 鄭鴻, 何冰, 譚宏昌, 等. 不同手術入路髖臼假體放置角度差異對療效的影響. 中華創傷骨科雜志, 2013, 15(8):734-736.
18. Hirakawa K, Mitsugi N, Koshino T, et al. Effect of acetabular cup position and orientation in cemented total hip arthroplasty. Clin Orthop Relat Res, 2001, (388):135-142.
19. Eggli S, Hankemayer S, Muller ME. Nerve palsy after leg lengthening in total replacement arthroplasty for developmental dysplasia of the hip. J Bone Joint Surg (Br), 1999, 81(5):843-845.
