<i>In vitro</i> hydrodynamic performance testing of heart valve prosthesis and its clinical application_Chinese Journal of Clinical Thoracic and Cardiovascular Surgery

Authors：

WANG Hao ¹ , ZHU Da ² , BAO Xiangyu ³ , HE Zhaoming ⁴ ,  LIU Li ⁵ ,  PAN Xiangbin ^2,6

1. Research Center of Fluid Machinery Engineering & Technology, Jiangsu University, Zhenjiang, 212013, Jiangsu, P. R. China;
2. Structural Heart Center, Fuwai Yunnan Cardiovascular Hospital, Kunming, 650000, P. R. China;
3. Shanghai Heartpartner Testing Equipment Co., Ltd, Shanghai, 200000, P. R. China;
4. Department of Mechanical Engineering, Texas Tech University, Lubbock, TX 79409, The United States of America;
5. National Institutes for Food and Drug Control, Beijing, 102629, P. R. China;
6. Structural Heart Center, National Center for Cardiovascular Diseases, Fuwai Hospital, Chinese Academy of Medical Sciences, Beijing, 100037, P. R. China;

Corresponding?author：

LIU Li, Email: liuli_7823@163.com; PAN Xiangbin, Email: xiangbin428@hotmail.com

Keywords：

Heart valve prosthesis; in vitro testing; hydrodynamic performance; ISO 5840 international standard

DOI：

10.7507/1007-4848.202111008

Video：

Export PDF Favorites Scan Get Citation

Abstract Full text Figures/Tables Video References Cited by

The heart valve prosthesis must have excellent hydrodynamic performance which is usually tested in vitro, not in vivo. This paper comprehensively introduced the principles and methods of hydrodynamic performance in vitro testing, helping clinicians to understand valve performance parameters, evaluate valve applicability, and reduce clinical risk of the valve prosthesis. In vitro testing not only serves as the "gold standard" for valve prosthesis assessment, but also provides detailed data for design and optimization of the prosthesis. ISO 5840 defines the items and methods for valve in vitro testing, which consists of three parts: (1) pulsatile flow testing, which reproduces the pulsating flow of the valve prosthesis after implantation in the human body; (2) steady flow testing, which assesses valve forward flow resistance; (3) durability testing, which evaluates the durability of the valve prosthesis and determines the expected failure mode. In addition, the paper presented the differences between atrioventricular and aortic valve testing, the method of mitral valve testing, the differences between transcatheter and surgical valve testing, and the method of valve flow visualization.

Citation： WANG Hao, ZHU Da, BAO Xiangyu, HE Zhaoming, LIU Li, PAN Xiangbin. In vitro hydrodynamic performance testing of heart valve prosthesis and its clinical application. Chinese Journal of Clinical Thoracic and Cardiovascular Surgery, 2022, 29(3): 279-287. doi: 10.7507/1007-4848.202111008 Copy
