Value of preoperative simulation in the treatment of transjugular intrahepatic portosystemic shunt_CHINESE JOURNAL OF BASES AND CLINICS IN GENERAL SURGERY

Authors：

 WEI Xin , HU Hong , ZHONG Liming , YOU Jian

Department of Interventional Radiology, Nanchong Central Hospital, Second Clinic Institute of North Sichuan Medical College, Nanchong, Sichuan 637000, P. R. China;

Corresponding?author：

WEI Xin, Email: wxzyy1998@sina.com

Keywords：

portal hypertension; transjugular intrahepatic portosystemic shunt; three-dimensional reconstruction; simulation

DOI：

10.7507/1007-9424.201908053

Video：

Export PDF Favorites Scan Get Citation

Abstract Full text Figures/Tables Video References Cited by

Objective To evaluate the value of individualized preoperative simulation in transjugular intrahepatic portosystemic shunt (TIPS).Methods Thin slice scan data of 39 patients with supine upper abdomen were obtained, three dimensional structures of bone, liver, portal vein, inferior vena cava and hepatic vein in CT scan area were reconstructed in Mimics software. According to the size of interventional instruments, a virtual RUPS-100 puncture kit and an VIATORR stent were established in 3D MAX software. Computer simulations were performed to evaluate the route from the hepatic vein puncture portal vein and stent release position. The coincidence of simulation parameters with actual surgical results was compared.Results ① The time of preoperative simulation was controllable. The total simulation time was 70–110 minutes (after summing up the previous experience). Preoperative simulation in daily work would not affect the progress of treatment. ② There were 4 cases of puncturing bifurcation of portal vein, 22 cases of puncturing left branch and 13 cases of puncturing right branch during operation (24 cases of puncturing left branch and 15 cases of puncturing right branch by preoperative simulation plan). The overall coincidence rate was 89.7% (35/39). ③ Preoperative simulations were performed using 8 mm×6 cm/2 cm size VIATORR stents, and the stents used in the actual operation were the same as the simulation results. ④ Preoperative simulation and post-operative retrospective simulation could shortened the teaching and training time and enhanced the understanding of surgical intention and key steps.Conclusion Preoperative simulation based on patient's individualized three-dimensional model and virtual interventional device could guided the actual operation of TIPS more accurately, and had practical value for improving the success rate of operation and training young doctors.

Citation： WEI Xin, HU Hong, ZHONG Liming, YOU Jian. Value of preoperative simulation in the treatment of transjugular intrahepatic portosystemic shunt. CHINESE JOURNAL OF BASES AND CLINICS IN GENERAL SURGERY, 2019, 26(12): 1424-1428. doi: 10.7507/1007-9424.201908053 Copy
