Wind environment simulation of Wuhan Huoshenshan Hospital and response of planning analysis to epidemic prevention work_West China Medical Journal

Authors：

 SUN Qiang ^1,2

1. College of Tourism and Urban-rural Planning, Chengdu University of Technology, Chengdu, Sichuan 610059, P. R. China;
2. Hanjia Design Group Co., ltd, Jinan, Shandong 250014, P. R. China;

Corresponding?author：

SUN Qiang, Email: 382738845@qq.com

Keywords：

Wuhan Huoshenshan Hospital; Wind environment simulation; PHOENICS software; Planning analysis; 2019 new coronavirus

DOI：

10.7507/1002-0179.202002024

Video：

Export PDF Favorites Scan Get Citation

Abstract Full text Figures/Tables Video References Cited by

Objective To specify the specific wind environment conditions of the outdoor wind speed field and wind pressure field in Wuhan Huoshenshan Hospital, identify the epidemic prevention area under special conditions such as daily cleaning and disinfection as well as accidents, and provide technical references for epidemic prevention work.Methods The network open data were adopted to build 3D models of buildings in Wuhan Huoshenshan Hospital and surrounding areas by using Auto CAD 2008 software, and then PHOENICS 2011 software was used to parameterize settings to simulate winter outdoor wind speed and wind pressure fields, to identify the epidemic prevention area under special conditions such as daily cleaning and disinfection as well as accidents.Results In the prevailing wind direction, the speeds of wind towards the No. 1 building, the intensive care unit and the reception area for confirmed patients transferred by ambulance, the No.2 building, and the temporary storage room of the isolation medical area are 1.0?1.5, 2.5?3.0, 2.0?2.5, and 3.0?3.5 m/s, respectively; the speed of wind towards the living area for medical staff is 2.5 m/s. In the isolation medical area, the pressure difference between the windward side and the leeward side of the building in the first row of the windward side is ≥5 Pa, and those of the rest buildings are ≥0.5 and ≤5 Pa; in the living area for medical staff, the pressure difference between the windward side and the leeward side of the north of the building is ≥5 Pa, while that of the south of the building is ≤0.5 Pa.Conclusion On the whole, there are areas with poor ventilation and at risk of pollutants gathering in Wuhan Huoshenshan Hospital, so the daily cleaning and disinfection work and epidemic prevention work of accident and other special circumstances should be done well.

Citation： SUN Qiang. Wind environment simulation of Wuhan Huoshenshan Hospital and response of planning analysis to epidemic prevention work. West China Medical Journal, 2020, 35(3): 274-279. doi: 10.7507/1002-0179.202002024 Copy

1.	李進, 李文全, 聶濱, 等. 輸入型難辨性新型冠狀病毒肺炎一例及傳播模式分析. 華西醫學, 2020, 35(2): 137-140.
2.	中華人民共和國國家衛生健康委員會. 中華人民共和國國家衛生健康委員會公告[2020 年第 1 號]. (2020-01-20)[2020-02-01]. http://www.nhc.gov.cn/xcs/zhengcwj/202001/44a3b8245e8049d2837a4f27529cd386.shtml.
3.	徐祥麗, 楊牧. 世界衛生組織將新型冠狀病毒疫情列為 PHEIC. (2020-01-31)[2020-02-24]. http://world.people.com.cn/n1/2020/0131/c1002-31565617.html.
4.	杜佳寧, 王岳人, 趙軍凱. 既有醫院建筑室內風環境模擬及評估. 節能, 2017(6): 7-10.
5.	張旻. 基于建筑風環境理念下的太原地區綠色醫院建筑設計研究. 太原: 太原理工大學, 2016.
6.	劉超, 周建民. 基于 PKPM 綠色建筑軟件的醫院建筑室內外風環境模擬及評價. 建筑節能, 2020, 48(1): 24-29.
7.	Argirious A, Asimakopoulos CA, Balaras E, et al. On the energy consumption and indoor air quality in office and hospital buildings in Athens, Hellas. Energy Convers Manag, 1994, 35(5): 385-394.
8.	Szklo AS, Soares JB, Tolmasquim MT. Energy consumption indicators and CHP technical potential in the Brazilian hospital sector. Energy Convers Manag, 2004, 45(13/14): 2075-2091.
9.	武漢市人民政府. 自然資源. (2019-01-07)[2020-02-01]. http://www.wh.gov.cn/2018wh/zjwh_5785/whgk/201808/t20180824_223222.html.
10.	中國氣象局氣象信息中心氣象資料室, 清華大學建筑技術科學系. 中國建筑熱環境分析專用氣象數據集. 北京: 中國建筑工業出版社, 2005: 137.
11.	張文福, 何俊美, 帖金鳳, 等. 冠狀病毒的抵抗力與消毒. 中國消毒學雜志, 2020, 30(1): 63-67.
12.	中華人民共和國住房和城鄉建設部, 國家市場監督管理總局. 綠色建筑評價標準: GB/T 50378－2019. 北京: 中國建筑工業出版社, 2019: 30-31.
13.	嚴婧, 王海軍, 程亞平, 等. 人工與自動觀測靜風的差異分析與應用. 氣象, 2017, 43(2): 232-239.
14.	孫玫玲, 韓素芹, 姚青, 等. 天津市城區靜風與污染物濃度變化規律的分析. 氣象與環境學報, 2007, 23(2): 21-24.
15.	王芳芳, 李蘭, 吳鈞. 武漢市空氣污染物分布及日變化特征與氣象因子的關系//中國氣象學會 2008 年年會大氣環境監測、預報與污染物控制分會場. 北京: 中國氣象學會, 2008: 5.
16.	歐陽芬, 吳荷玉, 楊英, 等. 基于武漢新型冠狀病毒肺炎快速傳播的應對措施. 全科護理, 2020, 18(3). (2020-01-31)[2020-02-02]. http://kns.cnki.net/kcms/detail/14.1349.R.20200131.1319.002.html.

1. 李進, 李文全, 聶濱, 等. 輸入型難辨性新型冠狀病毒肺炎一例及傳播模式分析. 華西醫學, 2020, 35(2): 137-140.
2. 中華人民共和國國家衛生健康委員會. 中華人民共和國國家衛生健康委員會公告[2020 年第 1 號]. (2020-01-20)[2020-02-01]. http://www.nhc.gov.cn/xcs/zhengcwj/202001/44a3b8245e8049d2837a4f27529cd386.shtml.
3. 徐祥麗, 楊牧. 世界衛生組織將新型冠狀病毒疫情列為 PHEIC. (2020-01-31)[2020-02-24]. http://world.people.com.cn/n1/2020/0131/c1002-31565617.html.
4. 杜佳寧, 王岳人, 趙軍凱. 既有醫院建筑室內風環境模擬及評估. 節能, 2017(6): 7-10.
5. 張旻. 基于建筑風環境理念下的太原地區綠色醫院建筑設計研究. 太原: 太原理工大學, 2016.
6. 劉超, 周建民. 基于 PKPM 綠色建筑軟件的醫院建筑室內外風環境模擬及評價. 建筑節能, 2020, 48(1): 24-29.
7. Argirious A, Asimakopoulos CA, Balaras E, et al. On the energy consumption and indoor air quality in office and hospital buildings in Athens, Hellas. Energy Convers Manag, 1994, 35(5): 385-394.
8. Szklo AS, Soares JB, Tolmasquim MT. Energy consumption indicators and CHP technical potential in the Brazilian hospital sector. Energy Convers Manag, 2004, 45(13/14): 2075-2091.
9. 武漢市人民政府. 自然資源. (2019-01-07)[2020-02-01]. http://www.wh.gov.cn/2018wh/zjwh_5785/whgk/201808/t20180824_223222.html.
10. 中國氣象局氣象信息中心氣象資料室, 清華大學建筑技術科學系. 中國建筑熱環境分析專用氣象數據集. 北京: 中國建筑工業出版社, 2005: 137.
11. 張文福, 何俊美, 帖金鳳, 等. 冠狀病毒的抵抗力與消毒. 中國消毒學雜志, 2020, 30(1): 63-67.
12. 中華人民共和國住房和城鄉建設部, 國家市場監督管理總局. 綠色建筑評價標準: GB/T 50378－2019. 北京: 中國建筑工業出版社, 2019: 30-31.
13. 嚴婧, 王海軍, 程亞平, 等. 人工與自動觀測靜風的差異分析與應用. 氣象, 2017, 43(2): 232-239.
14. 孫玫玲, 韓素芹, 姚青, 等. 天津市城區靜風與污染物濃度變化規律的分析. 氣象與環境學報, 2007, 23(2): 21-24.
15. 王芳芳, 李蘭, 吳鈞. 武漢市空氣污染物分布及日變化特征與氣象因子的關系//中國氣象學會 2008 年年會大氣環境監測、預報與污染物控制分會場. 北京: 中國氣象學會, 2008: 5.
16. 歐陽芬, 吳荷玉, 楊英, 等. 基于武漢新型冠狀病毒肺炎快速傳播的應對措施. 全科護理, 2020, 18(3). (2020-01-31)[2020-02-02]. http://kns.cnki.net/kcms/detail/14.1349.R.20200131.1319.002.html.
