Objective To investigate the application value of three-dimensional reconstruction and virtual pre-operative planning for Pilon fractures.
Methods Between July 2010 and June 2014, 16 patients with closed Pilon fracture were treated, including 12 males and 4 females with an average age of 36.5 years (range, 22-53 years) and a mean disease duration of 10.2 days (range, 6-14 days). According to AO/Orthopaedic Trauma Association (AO/OTA) typing, 2 cases were rated as 43.B2 type, 3 cases as 43.B3 type, 3 cases as 43.C1 type, 2 cases as 43.C2 type, and 6 cases as 43.C3 type. The preoperative CT data from 16 patients were imported into Mimics10.01 software to establish the detailed fracture three-dimensional digital models. Virtual operation of fracture reduction and implanting internal fixation was performed on the models, and the optional surgical planning was made. Based on the virtual preoperative planning, operations were performed.
Results Established detailed three-dimensional Pilon fracture digital models could perfectly reflect the fracture characteristics, could be observed at any direction, and aided for fracture classification accurately. Virtual fracture operations of reduction, internal fixation and other could be performed to simulate the clinical operation, which could assist the surgeon better preoperative planning in achieving visual presentation and improving the communication. The operation time was 70-130 minutes (mean, 87.8 minutes); intraoperative blood loss volume was 30-150 mL (mean, 71.9 mL). The wounds healed by first intension in all patients. The mean follow-up time was 11.6 months (range, 8-18 months). Postoperative radiological results at 3 groups showed good anatomic reduction according to the Burwell-Charnley criteria, and the fracture healing time was 3-6 months (mean, 3.7 months). There was no complication of internal fixation loosening or breakage during follow-up. The American Orthopedic Foot and Ankle Society (AOFAS) score was 71-100(mean, 92.3); the results were excellent in 10 cases, good in 5 cases, and fair in 1 case, with an excellent and good rate of 93.8% at last follow-up. No loss of fracture reduction was observed on the X-ray film.
Conclusion The clinical feasibility of virtual reconstruction preoperative planning is good in the treatment of Pilon fractures, which helps surgeons better understanding Pilon fracure and making the surgical planning.
Citation：WANGXiaoping, WEIZhantu, HUANGJian, CHENLuyao, HUShiqiang, WUWeiwei, TUYumin, GUOSheng, XUGuotai, DENGZhicheng. PRELIMINARY APPLICATION OF VIRTUAL PREOPERATIVE RECONSTRUCTION PLANNING IN Pilon FRACTURES. Chinese Journal of Reparative and Reconstructive Surgery, 2016, 30(1): 44-49. doi: 10.7507/1002-1892.20160010Copy
Copyright ? the editorial department of Chinese Journal of Reparative and Reconstructive Surgery of West China Medical Publisher. All rights reserved
Thomas TP, Anderson DD, Willis AR, et al. A computational/experimental platform for investigating three-dimensional puzzle solving of comminuted articular fractures. Comput Methods Biomech Biomed Engin, 2011, 14(3):263-270.
5.
Stapleton JJ, Zgonis T. Surgical treatment of tibial plafond fractures. Clin Podiatr Med Surg, 2014, 31(4):547-564.
6.
Thomas TP, Anderson DD, Willis AR, et al. ASB Clinical Biomechanics Award Paper 2010 Virtual pre-operative reconstruction planning for comminuted articular fractures. Clin Biomech (Bristol Avon), 2011, 26(2):109-115.
Burwell HN, Charnley AD. The treatment of displaced fractures at the ankle by rigid internal fixation and early joint movement. J Bone Joint Surg (Br), 1965, 47(4):634-660.
12.
Kitaoka HB, Alexander IJ, Adelaar RS, et al. Clinical rating systems for the ankle-hindfoot, midfoot, hallux, and lesser toes. Foot Ankle Int, 1994, 15(7):349-353.
2. He X, Hu Y, Ye P, et al. The operative treatment of complex pilon fractures:A strategy of soft tissue control. Indian J Orthop, 2013, 47(5):487-492.
4. Thomas TP, Anderson DD, Willis AR, et al. A computational/experimental platform for investigating three-dimensional puzzle solving of comminuted articular fractures. Comput Methods Biomech Biomed Engin, 2011, 14(3):263-270.
5. Stapleton JJ, Zgonis T. Surgical treatment of tibial plafond fractures. Clin Podiatr Med Surg, 2014, 31(4):547-564.
6. Thomas TP, Anderson DD, Willis AR, et al. ASB Clinical Biomechanics Award Paper 2010 Virtual pre-operative reconstruction planning for comminuted articular fractures. Clin Biomech (Bristol Avon), 2011, 26(2):109-115.
11. Burwell HN, Charnley AD. The treatment of displaced fractures at the ankle by rigid internal fixation and early joint movement. J Bone Joint Surg (Br), 1965, 47(4):634-660.
12. Kitaoka HB, Alexander IJ, Adelaar RS, et al. Clinical rating systems for the ankle-hindfoot, midfoot, hallux, and lesser toes. Foot Ankle Int, 1994, 15(7):349-353.
