Three-dimensional printed Ti6Al4V-4Cu alloy promotes osteogenic gene expression through bone immune regulation_Chinese Journal of Reparative and Reconstructive Surgery

Authors：

ZHANG Chenke ^1,2 , LU Yanjin ³ , GUO Yupeng ² , CHEN Wan ² , TANG Hong ² , LI Huaisheng ² , TANG Kanglai ² ,  HE Qingyi ¹

1. Department of Orthopedics, the First Affiliated Hospital of Army Medical University of Chinese PLA, Chongqing, 400038, P.R.China;
2. Department of Orthopedics/Sports Medicine Center, the First Affiliated Hospital of Army Medical University of Chinese PLA, Chongqing, 400038, P.R.China;
3. Fujian Institute of Research on the Structure of Matter, Fuzhou Fujian, 350002, P.R.China;

Corresponding?author：

HE Qingyi, Email: qingyihe18625@163.com

Keywords：

Three-dimensional printing; Ti6Al4V-4Cu alloy; osteogenic microenvironment; bone immune regulation

DOI：

10.7507/1002-1892.201912139

Video：

Export PDF Favorites Scan Get Citation

Abstract Full text Figures/Tables Video References Cited by

Objective To investigate the effects of three-dimensional (3D) printed Ti6Al4V-4Cu alloy on inflammation and osteogenic gene expression in mouse bone marrow mesenchymal stem cells (BMSCs) and mouse mononuclear macrophage line RAW264.7.Methods Ti6Al4V and Ti6Al4V-4Cu alloys were prepared by selective laser melting, and the extracts of the two materials were prepared according to the biological evaluation standard of medical devices. The effects of two kinds of extracts on the proliferation of mouse BMSCs and mouse RAW264.7 cells were detected by cell counting kit 8 method. After co-cultured with mouse BMSCs for 3 days, the expression of osteogenesis- related genes [collagen type Ⅰ (Col-Ⅰ), alkaline phosphatase (ALP), Runx family transcription factor 2 (Runx-2), osteoprotegerin (OPG), and osteopontin (OPN)] were detected by real-time fluorescence quantitative PCR. After co-cultured with mouse RAW264.7 cells for 1 day, the expressions of inflammation-related genes [interleukin 4 (IL-4) and nitric oxide synthase 2 (iNOS)] were detected by real-time fluorescence quantitative PCR, and the supernatants of the two groups were collected to detect the secretion of vascular endothelial growth factor a (VEGF-a) and bone morphogenetic protein 2 (BMP-2) by ELISA. The osteogenic conditioned medium were prepared with the supernatants of the two groups and co-cultured with BMSCs for 3 days. The expressions of osteogenesis-related genes (Col-Ⅰ, ALP, Runx-2, OPG, and OPN) were detected by real-time fluorescence quantitative PCR.Results Compared with Ti6Al4V alloy extract, Ti6Al4V-4Cu alloy extract had no obvious effect on the proliferation of BMSCs and RAW264.7 cells, but it could promote the expression of OPG mRNA in BMSCs, reduce the expression of iNOS mRNA in RAW264.7 cells, and promote the expression of IL-4 mRNA. It could also promote the secretions of VEGF-a and BMP-2 in RAW264.7 cells. Ti6Al4V-4Cu osteogenic conditioned medium could promote the expressions of Col-Ⅰ, ALP, Runx-2, OPG, and OPN mRNAs in BMSCs. The differences were all significant (P<0.05).Conclusion 3D printed Ti6Al4V-4Cu alloy can promote RAW264.7 cells to secret VEGF-a and BMP-2 by releasing copper ions, thus promoting osteogenesis through bone immune regulation, which lays a theoretical foundation for the application of metal prosthesis.

Citation： ZHANG Chenke, LU Yanjin, GUO Yupeng, CHEN Wan, TANG Hong, LI Huaisheng, TANG Kanglai, HE Qingyi. Three-dimensional printed Ti6Al4V-4Cu alloy promotes osteogenic gene expression through bone immune regulation. Chinese Journal of Reparative and Reconstructive Surgery, 2020, 34(9): 1170-1176. doi: 10.7507/1002-1892.201912139 Copy
