Treatment of chronic thoracolumbar osteoporotic fractures combined with kyphosis with cement-injectable cannulated pedicle screw and multiple level Schwab grade <b>Ⅰ</b> osteotomy_Chinese Journal of Reparative and Reconstructive Surgery

Authors：

ZHANG Di ^1,2 , ZHANG Wenming ¹ , ZHOU Xianwei ¹ , SHEN Huiyong ² ,  JIN Song ²

1. Department of Spinal Surgery, Luoyang Orthopedic-Traumatological Hospital of Henan Province (Henan Provincial Orthopedic Hospital), Zhengzhou Henan, 450000, P.R.China;
2. Department of Orthopedics, the Eighth Affiliated Hospital of Sun Yat-sen University, Shenzhen Guangdong, 518033, P.R.China;

Corresponding?author：

JIN Song, Email: jingsosysu@tom.com

Keywords：

Cement-injectable cannulated pedical screw; Schwab gradeⅠosteotomy; osteoporosis; thoracolumbar fracture; kyphosis

DOI：

10.7507/1002-1892.202006129

Video：

Export PDF Favorites Scan Get Citation

Abstract Full text Figures/Tables Video References Cited by

Objective To evaluate the effectiveness of cement-injectable cannulated pedicle screw combined with multiple level Schwab grade Ⅰ osteotomy for chronic thoracolumbar osteoporotic fractures with kyphosis.Methods The clinical data of 27 patients with symptomatic chronic thoracolumbar osteoporotic fractures combined with kyphosis treated between June 2015 and June 2017 were retrospectively analysed. Among them, there were 8 males and 19 females, with an average age of 69.5 years (range, 56-81 years). The damage segment (kyphosis vertex) included T₁₁ in 4 cases, T₁₂ in 12 cases, L₁ in 10 cases, and L₂ in 1 case. The disease duration ranged from 3 to 21 months, with an average of 12.5 months. The T value of lumbar vertebral bone mineral density ranged from ?4.9 to ?2.5, with an average value of ?3.61. The American Spinal Injury Association (ASIA) classification was used to evaluate spinal cord injury, there were 1 case of grade D and 26 cases of grade E. The visual analogue scale (VAS) score, Oswestry disability index (ODI), kyphosis Cobb angle of fracture site, and sagittal vertical axis (SVA) data were obtained before operation, at 2 weeks after operation, 3 months after operation, and last follow-up, to evaluate the quality of life and improvement of sagittal spine parameters.Results No complications related to pedicle screw and bone cement occurred. The incisions healed by first intention in 26 cases, and 1 incision healed after dressing change due to poor blood glucose control. There were no complications such as bedsore, hypostatic pneumonia, or deep venous thrombosis. All patients were followed up 8-24 months, with an average of 16.6 months. The VAS score, ODI score, Cobb angle, and SVA were significantly improved when compared with those before operation (P<0.05). There was no significant difference in Cobb angle between each time point after operation (P>0.05); the VAS score and ODI score at 3 months after operation and last follow-up were significantly better than those at 2 weeks after operation (P<0.05), and the ODI score at last follow-up was further improved when compared with the score at 3 months (P<0.05), but there was no significant difference in VAS score (P>0.05); SVA at last follow-up was significantly worse than that at 2 weeks and 3 months after operation (P<0.05), but there was no significant difference between at 2 weeks and 3 months after operation (P>0.05). During the follow-up period, there was no complication such as pedicle screw loosening, breakage or cutting, adjacent vertebral fracture, proximal junctional kyphosis, and so on.Conclusion For the chronic thoracolumbar osteoporotic fractures combined with kyphosis, the cement-injectable cannulated pedicle screw and multiple level Schwab grade Ⅰ osteotomy has the advantages of less operation trauma, quick recovery, and remarkable effectiveness.

Citation： ZHANG Di, ZHANG Wenming, ZHOU Xianwei, SHEN Huiyong, JIN Song. Treatment of chronic thoracolumbar osteoporotic fractures combined with kyphosis with cement-injectable cannulated pedicle screw and multiple level Schwab grade Ⅰ osteotomy. Chinese Journal of Reparative and Reconstructive Surgery, 2020, 34(12): 1533-1538. doi: 10.7507/1002-1892.202006129 Copy

1.	Cummings SR, Melton LJ. Epidemiology and outcomes of osteoporotic fractures. Lancet, 2002, 359(9319): 1761-1767.
2.	Zaryanov AV, Park DK, Khalil JG, et al. Cement augmentation in vertebral burst fractures. Neurosurg Focus, 2014, 37(1): E5.
3.	王琨, 楊操, 楊述華, 等. 陳舊性胸腰椎骨折伴后凸畸形的截骨矯形術式選擇. 中國脊柱脊髓雜志, 2016, 26(1): 24-29.
4.	毛貝尼, 張鐘, 付維力, 等. 中國骨質疏松性骨折疾病負擔的系統評價. 中國循證醫學雜志, 2018, 18(2): 151-155.
5.	中華醫學會骨科學分會骨質疏松學組. 骨質疏松性骨折診療指南. 中華骨科雜志, 2017, 37(1): 1-10.
6.	Schwab F, Patel A, Ungar B, et al. Adult spinal deformity-postoperative standing imbalance: how much can you tolerate? An overview of key parameters in assessing alignment and planning corrective surgery. Spine (Phila Pa 1976), 2010, 35(25): 2224-2231.
7.	張義龍, 任磊, 孫志杰, 等. 椎體成形術后新發椎體骨折與脊柱矢狀位參數的相關性分析. 重慶醫學, 2017, 46(4): 483-485.
8.	Schwab F, Blondel B, Chay E, et al. The comprehensive anatomical spinal osteotomy classification. Neurosurgery, 2014, 74(1): 112-120.
9.	張銀昌, 趙清華, 秦曉東, 等. SRS-Schwab Ⅳ級截骨聯合衛星棒技術治療胸腰椎陳舊性骨質疏松性骨折伴嚴重后凸畸形. 中國修復重建外科雜志, 2019, 33(3): 259-264.
10.	Cho KJ, Bridwell KH, Lenke LG, et al. Comparison of Smith-Petersen versus pedicle subtraction osteotomy for the correction of fixed sagittal imbalance. Spine (Phila Pa 1976), 2005, 30(18): 2030-2037.
11.	Halvorson TL, Kelley LA, Thomas KA, et al. Effects of bone mineral density on pedicle screw fixation. Spine (Phila Pa 1976), 1994, 19(21): 2415-2420.
12.	McLain RF, McKinley TO, Yerby SA, et al. The effect of bone quality on pedicle screw loading in axial instability. A synthetic model. Spine (Phila Pa 1976), 1997, 22(13): 1454-1460.
13.	Pezowicz C, Filipiak J. Influence of loading history on the cervical screw pullout strength value. Acta Bioeng Biomech, 2009, 11(3): 35-40.
14.	Rohmiller MT, Schwalm D, Glattes RC, et al. Evaluation of calcium sulfate paste for augmentation of lumbar pedicle screw pullout strength. Spine J, 2002, 2(4): 255-260.
15.	Tai CL, Tsai TT, Lai PL, et al. A biomechanical comparison of expansive pedicle screws for severe osteoporosis: The effects of screw design and cement augmentation. PLoS One, 2015, 10(12): e0146294.
16.	Hsu WL, Lin YH, Chuang HY, et al. Cortical bone trajectory instrumentation with vertebroplasty for osteoporotic thoracolumbar compression fracture. Medicina (Kaunas), 2020, 56(2): 82.
17.	Yang SC, Liu PH, Tu YK. Pullout evaluation of sawbone experiment in different types of pedicle screws combined with bone cement augmentation for severe osteoporotic spine. Acta Bioeng Biomech, 2018, 20(2): 55-64.
18.	Kiyak G, Balikci T, Heydar AM, et al. Comparison of the pullout strength of different pedicle screw designs and augmentation techniques in an osteoporotic bone model. Asian Spine J, 2018, 12(1): 3-11.
19.	陳曉峰, 李浩, 歐志聰, 等. 不同置釘和骨水泥劑量對椎弓根螺釘固定強度的影響. 中國矯形外科雜志, 2019, 27(14): 1306-1310.
20.	Liu YY, Xiao J, Yin X, et al. Clinical efficacy of bone cement-injectable cannulated pedicle screw short segment fixation for lumbar spondylolisthesis with osteoporosise. Sci Rep, 2020, 10(1): 3929.
21.	陳建良, 許勇, 萬蕾, 等. 老年骨質疏松性陳舊胸腰椎骨折伴后凸畸形后路截骨矯形的術式選擇. 中國骨傷, 2020, 33(2): 121-126.
22.	張健, 王小健, 秦德安, 等. 脊柱矯形后發生近端交界性后凸危險因素的薈萃分析. 中國組織工程研究, 2020, 24(3): 460-468.

1. Cummings SR, Melton LJ. Epidemiology and outcomes of osteoporotic fractures. Lancet, 2002, 359(9319): 1761-1767.
2. Zaryanov AV, Park DK, Khalil JG, et al. Cement augmentation in vertebral burst fractures. Neurosurg Focus, 2014, 37(1): E5.
3. 王琨, 楊操, 楊述華, 等. 陳舊性胸腰椎骨折伴后凸畸形的截骨矯形術式選擇. 中國脊柱脊髓雜志, 2016, 26(1): 24-29.
4. 毛貝尼, 張鐘, 付維力, 等. 中國骨質疏松性骨折疾病負擔的系統評價. 中國循證醫學雜志, 2018, 18(2): 151-155.
5. 中華醫學會骨科學分會骨質疏松學組. 骨質疏松性骨折診療指南. 中華骨科雜志, 2017, 37(1): 1-10.
6. Schwab F, Patel A, Ungar B, et al. Adult spinal deformity-postoperative standing imbalance: how much can you tolerate? An overview of key parameters in assessing alignment and planning corrective surgery. Spine (Phila Pa 1976), 2010, 35(25): 2224-2231.
7. 張義龍, 任磊, 孫志杰, 等. 椎體成形術后新發椎體骨折與脊柱矢狀位參數的相關性分析. 重慶醫學, 2017, 46(4): 483-485.
8. Schwab F, Blondel B, Chay E, et al. The comprehensive anatomical spinal osteotomy classification. Neurosurgery, 2014, 74(1): 112-120.
9. 張銀昌, 趙清華, 秦曉東, 等. SRS-Schwab Ⅳ級截骨聯合衛星棒技術治療胸腰椎陳舊性骨質疏松性骨折伴嚴重后凸畸形. 中國修復重建外科雜志, 2019, 33(3): 259-264.
10. Cho KJ, Bridwell KH, Lenke LG, et al. Comparison of Smith-Petersen versus pedicle subtraction osteotomy for the correction of fixed sagittal imbalance. Spine (Phila Pa 1976), 2005, 30(18): 2030-2037.
11. Halvorson TL, Kelley LA, Thomas KA, et al. Effects of bone mineral density on pedicle screw fixation. Spine (Phila Pa 1976), 1994, 19(21): 2415-2420.
12. McLain RF, McKinley TO, Yerby SA, et al. The effect of bone quality on pedicle screw loading in axial instability. A synthetic model. Spine (Phila Pa 1976), 1997, 22(13): 1454-1460.
13. Pezowicz C, Filipiak J. Influence of loading history on the cervical screw pullout strength value. Acta Bioeng Biomech, 2009, 11(3): 35-40.
14. Rohmiller MT, Schwalm D, Glattes RC, et al. Evaluation of calcium sulfate paste for augmentation of lumbar pedicle screw pullout strength. Spine J, 2002, 2(4): 255-260.
15. Tai CL, Tsai TT, Lai PL, et al. A biomechanical comparison of expansive pedicle screws for severe osteoporosis: The effects of screw design and cement augmentation. PLoS One, 2015, 10(12): e0146294.
16. Hsu WL, Lin YH, Chuang HY, et al. Cortical bone trajectory instrumentation with vertebroplasty for osteoporotic thoracolumbar compression fracture. Medicina (Kaunas), 2020, 56(2): 82.
17. Yang SC, Liu PH, Tu YK. Pullout evaluation of sawbone experiment in different types of pedicle screws combined with bone cement augmentation for severe osteoporotic spine. Acta Bioeng Biomech, 2018, 20(2): 55-64.
18. Kiyak G, Balikci T, Heydar AM, et al. Comparison of the pullout strength of different pedicle screw designs and augmentation techniques in an osteoporotic bone model. Asian Spine J, 2018, 12(1): 3-11.
19. 陳曉峰, 李浩, 歐志聰, 等. 不同置釘和骨水泥劑量對椎弓根螺釘固定強度的影響. 中國矯形外科雜志, 2019, 27(14): 1306-1310.
20. Liu YY, Xiao J, Yin X, et al. Clinical efficacy of bone cement-injectable cannulated pedicle screw short segment fixation for lumbar spondylolisthesis with osteoporosise. Sci Rep, 2020, 10(1): 3929.
21. 陳建良, 許勇, 萬蕾, 等. 老年骨質疏松性陳舊胸腰椎骨折伴后凸畸形后路截骨矯形的術式選擇. 中國骨傷, 2020, 33(2): 121-126.
22. 張健, 王小健, 秦德安, 等. 脊柱矯形后發生近端交界性后凸危險因素的薈萃分析. 中國組織工程研究, 2020, 24(3): 460-468.
